2006 SEA RAY 58 SEDAN BRIDGE

Manufacturer Description
More powerful and adventurous than any other yacht in its class, the 58 Sedan Bridge is ready to take command of the water. Its bold, dynamic styling includes a fiberglass hardtop as well as the very latest in marine electronics. Driven by powerful twin MAN V8 diesel inboards, this Sedan Bridge has a higher fuel capacity than most yachts in its category, plus all the strength and durability you’ll need for exploring rougher waters.

Hull and Deck Features

Bow Rail, 316 Stainless Steel w/Welded Stanchions, Intermediate Rails & Life Lines
Cleats, Custom Sea Ray® Thru-Bolted – Stainless Steel (8)
Deck Fill Plates, Stainless Steel
Deck Rails, 316 Stainless Steel
Handrails, 316 Stainless Steel
Portlights, Stainless Steel (6 Fixed, 2 Opening)
Resin, High-Performance Vinylester
Rub Rail, PVC w/Stainless Steel Insert
Storage, Transom Wall – (For Fenders & Gear)
Swim Platform, Extended w/Concealed Stainless Steel Ladder & Grab Handle

Windlass System:
Anchor, Galvanized
Anchor Chain Storage w/Hatch
Anchor Chute, Stainless Steel
Anchor Washdown Spigot w/Hose
Windlass, Chain w/Foot Switches

Canvas:
Custom Aft Cockpit Sunshade Cover
New Hardtop Flybridge Enclosure

Certifications:
Meets Applicable USCG & ABYC Standards
NMMA Yacht Certification

Swim Step
The large hi-lo swim platform holds a 2018 11.5’ Pearl Grey Achilles HB-350 DX 6 person/1,650lb tender.  Featuring underwater lights, Fusion stereo, and a Yamaha 25hp 4-stroke outboard motor.  (Beam 5’9” Length 11.5’)

Hi-lo swim platform
Adjustable chalks
(2) Stainless Steel cleats
Transom Storage Compartment
Glendenning Cable Master System (access through transom storage cabinet)

Cockpit Features
Teak Deck
(3) Molded-in Live Bait Wells in Aft Coaming
(18) Custom Stainless Steel Rod Holders
(4) Rod Holders flush mounted into the combings
Extended Overhead sunshade with new canvas and stainless steel frame
Portable and Adjustable Teak Table
Aft Bench Seating w/Fiberglass Storage Base (Removable)
Cabin Entry Door (Sliding & Lockable)
Transom Door
Engine Hatch
Indirect and Overhead Lighting (Blue Courtesy Lights)
120V GFI Protected Outlet
Hot/Cold Fresh Water Shower
Molded Teak Steps Leading to the Flybridge
Fuel Shut off valves (in starboard cabinet)
Onan Generator Gauges (in starboard cabinet)
Fusion Audio remote head
Storage cabinet under Staircase to Fly
Storage cabinet to port

Flybridge

Fiberglass Hardtop  w/Overhead Storage, (20×20) Hatch w/Stainless Steel Grab Rails, Overhead Lighting w/Electronic Dimmer & Red Night Lighting
NEW Enclosure
Uline Icemaker, 120V
Wet Bar w/Sink, Removable Trash  Receptacle & Storage
Indirect Lighting
12V Accessory Outlet
120V GFI Protected Outlet
Samsung Flat Screen TV
Fusion Stereo System with (4) overhead speakers and a sub-woofer
Norcold Refrigerator, 120V
Aft Bench Seating
Helm (2) Seating w/Flip-Up Thigh-Rise Bolsters, Armrests & Heavy-Duty Pedestals          w/Slides, Swivels & Pneumatic Vertical Adjustments
U-Shaped Seating w/Storage Below and Forward
Fiberglass Table
Storage Drawer at Helm

Helm

Richie Compass
Fusion Stereo at the helm with remote head forward
(2) Raymarine Hybridtouch Multi-Function Displays
Raymarine VHF RAY49
Raymarine VHF  RAYMic260
Side-Power Bow & Stern Thruster Control
Bennett Trim Tab Controls
Raymarine Auto Pilot
Raymarine Remote display
ACR Remote Spotlight Control
Adjustable Pilot and Co-Pilot Seats
Rudder angle indicator
MAN Engine Monitors
SeaRay Systems Monitor
Overhead storage

Salon

Enter the salon through the large aft cockpit door and enter an inviting and comfortable salon that can seat 6 people with two ultra-leather sofas facing one another on port and starboard.  More added comfort with two ottomans that double as storage bins.  Large windows let plenty of natural light in with both overhead and indirect lighting for nighttime enjoyment.  The large flat-screen TV connected to Sat TV receiver is perfectly placed in the aft starboard corner.

Dimmable Overhead Lighting
Love seat to starboard with ample storage underneath
Sofa to Port with pull out bed and storage fore and aft
Wood Blinds
AC/DC Panel behind smoked glass
A/V equipment
Samsung flat-screen TV
Bose Audio with surround Sound
Sat TV Receiver
Drawer storage under TV
Cabinet above TV
Glomax TV Antenna
Sirius Sat Radio Receiver
Wood Floors
Aft Privacy Curtain
Xantrex Inverter Control Panel
FCI Watermaker Control Panel
AC/Heating Vents throughout

Galley

One step up and forward of the salon is a full-featured galley accented by a comfortable settee to port.  The galley boasts ample counter space and abundant storage.  The owner upgraded the galley with a new wine refrigerator and installed a drinking water filtration system.

N Finity Pro Wine Refrigerator
Sub Zero drawer refrigerator
Water Filtration System
Two-Burner Princess Electric Stove
Vent
(4) Countertop outlets
12V Counter top power plug
Stainless Steel Sink
Solid Surface Counter Top
(6) Storage Drawers
Cabinet with pull out trash can
Direct and indirect lighting
Settee table has (3) drawers
Bottle storage in cabinet separating salon and Salon/Settee
AC/Heating Vents throughout

Accommodations:

Master Stateroom:
Queen-sized Bed
Door, Privacy w/Full-Length
Beveled Mirror
Hanging Locker, Maple-Lined w/Light
Storage, Dresser w/Drawers & Lift
Top Vanity
Storage, Locker – Maple-Lined
w/Adjustable Shelves
Samsung Flat Screen TV

Master Ensuite Head/Shower:
Bath Accessories, Satin Finish
Handrails, Elliptical Stainless Steel
VacuFlush® Toilet
Power Vent, 24V
Shower w/Seat, Shower Wand &
Acrylic Door
Storage, Medicine Cabinet – Mirrored
Vanity w/Solid Surface Countertop,
Solid Surface Sink w/Grohe Faucet &
Storage Below

Forward Stateroom:
Queen Size Bed Bed with Drawers &
Carpeted Storage Below w/Gas-Assisted Hatch
Hanging Locker, Maple-Lined w/Light
Mirrored Rope Locker Bulkhead
Storage, Cabinet w/Drawers – Port
Samsung Flatscreen TV

Guest Stateroom:

Single Berth
Overhead Storage
Large Storage Cabinet
Expansive Underbed Storage
Samsung Flat Screen TV

Guest Head/Shower:
Bath Accessories, Satin Finish
Door, Privacy – Access from Hallway and Forward Stateroom
VacuFlush Toilet
Shower w/Seat & Adjustable
Shower Wand
Storage, Medicine Cabinet – Mirrored
Vanity w/Solid Surface Countertop,
Solid Surface Sink w/Grohe® Faucet,
Mirrors & Storage Below

Stackable Full-Size Washer and Dryer in Companionway
Kenmore

Technical Features:

Control Station:
Alarms, Bilge Temperature to
Systems Monitor
Alarms, High-Water – Bilge
Emergency Engine Stop
Emergency Start System – Engines
Horn, Air – 24V w/Accumulator Tank
Instrument Panels – Brushed Metal
Instrumentation, Custom Sea Ray®
Backlit w/Low-Glare Blue Night
Lighting & Stainless Steel Bezels
[(Includes: Engine Sync, Fuel (2),
Oil Pressure (2), Tachometers
w/LCD Hourmeters, Voltmeters (2),
Water Temperature (2)]
Shift & Throttle Controls, Electronic
Spotlight w/Dual Halogen Bulbs –
Remote-Controlled (ACR®)
Steering, Hydraulic – Power-Assisted
Steering, Tilt Wheel
Steering Wheel, Wood-Accent
Switch Panel (Backlit) – Brushed Metal
Switches, Illuminated Weatherproof
Rockers & Electronic Dimmer Control

Electrical Systems:
Batteries, 8-D w/Boxes (4) & Group 27
For Genset (1)
Battery Charger/Converter, 120V/10
Amp/12V
Battery Charger/Converter, 240V/50
Amp/24V
Battery Charger Overcurrent Protection
Battery Equalizer, 60 Amp (2)
Battery Solenoid Switches, 12V (2),
24V (2)
Panel, Circuit Breaker – Remote
Panel, DC Main Breaker
Panel, Main Distribution – AC, Housed
in an Aluminum Enclosure
Panel, Main Distribution – DC, Housed
in an Aluminum Enclosure
Shore Power, Cablemaster
(Glendinning) 50 Amp/240V/60 Cycle
w/50′ Cord
Transformer, Shore Power Isolation –
50 Amp/240V/60 Cycle
Wiring, Color-Coded & Labeled
w/Chafe Protection

Generator:
Remote Start w/Muffler, Freshwater
Cooling, Fuel Filter, Seacock &
Seawater Strainer w/Battery, 240V
17.0 kW Onan® Diesel
w/Sound Shield

Air Conditioning/Heating
(Bridge):
Reverse-Cycle System, 240V
(24,000 BTU)

Air Conditioning/Heating
(Cabin):
Zone-Controlled Reverse-Cycle System,
240V (49,000 BTU)
Custom Integral Vent System

Engine Room:
Bilge Pumps, 24V Automatic
(2 Bilge, 1 Fwd Cabin)
Bilge Pumps, 24V Automatic High-Water
(1 Bilge, 1 Fwd Cabin)
Exhaust, Power Pac/Lift System
Mufflers & Sound Insulation
Fan
Fire Extinguishers
Fire Suppression System – Automatic
(Dual) w/Diesel Shutdown, Override
& Manual Pull
Flooring, Fiberglass Diamond Plate
Freshwater Cooling
Gel-Coated Engine Room, Oyster
Ladder, Stainless Steel –
Removable/Swing-Away
Lighting, 24V
Oil Changer System – Engines,
Transmissions & Generator
Storage Rack
Synchronizer, Engines

Fuel System:
Crossover Fuel System (Generator Only)
Fuel Filters (3) (Racor®) (2) 75-
1000MAX (Dual) for Engines (1)
500MA for Generator
Fuel Lines, USCG – Type A-1
Fuel Tanks, Aluminum w/Electric
Sending Units (2)

Water System:
Freshwater Hose & Spigot – Engine Room
Freshwater Washdown & Dockside Inlet
w/Cockpit Shower – Hot & Cold
Pressure Water System w/Dual
24V Pumps
Water Heater, 240V (18-Gallon)
Water Manifold System
Water Tank (150-Gallon)

Waste Systems:
Cabin Sump Pump, 24V – Shower/
Air Conditioning Condensate
w/Hinged Service Lid
Central Drain System
Head System (VacuFlush®)
Holding Tank Level Indicators – MDP
& Heads
Holding Tank w/Dockside Pump-Out &
Automatic Cut-Off (68-Gallon)
Macerator w/Seacock Interlock System

Underwater Gear:
Bonding System w/Zinc Hull Plate
Propeller Shafts, 2 1/2″ Stainless Steel (2)
Propellers, Nibral 4-Blade Cup
Rudders, Manganese-Bronze w/Stainless Steel Posts
Seacocks on all Underwater Fittings
Seawater Strainers
Shaft Logs, Dripless
Struts, Manganese-Bronze
Trim Tabs, 24V Hydraulic Transom-Mounted, Heavy-Duty, Dual Rams w/Pump
